ABC Cable Aluminum Aerial Bundle Cables DES/LVC-IEC 60502 AL XLPE 0.6/1kV

ABC Cable Aluminum Aerial Bundle Cables DES/LVC-IEC 60502 AL XLPE 0.6/1kV

Name : ABC Cable Aluminum Aerial Bundle Cables DES/LVC-IEC 60502 AL XLPE 0.6/1kV

Conductor : H68 Aluminium Conductor

Insulation : XLPE

Voltage : 0.6/1kV

Number of cores: 2-5 cores

Package : Export wooden drum & iron wooden drum or as customer require

Email: manager@hdcable.com.cn

ABC Cable DES/LVC-IEC 60502 Application

The aerial bundled cables designed for overhead distribution lines have all conductors made of aluminium 1350 and insulated with XLPE. Can be used for fixed installation as overhead power lines up to 1000 V incl.

ABC Cable DES/LVC-IEC 60502 Strandard

DES/LVC/ABC Specification; IEC 60502
CONSTRUCTION :

 ABC Cable DES/LVC-IEC 60502 Construction

CONDUCTOR
H68 aluminium conductor and compacted circular stranded (RM).
INSULATION
XLPE
ASSEMBY The cores shall be laid up with a left-hand lay.



1. CONCUTOR 2. INSULATION
TECHNICAL DATA :

Rated voltage

kV

0.6/1

Test voltage

Veff kV/Hz

4/50

Laying temperature

°C

min. -5

Operating temperature

°C

-30 ~ +90

Conductor temperature

°C

max. +90

Short-circuit temperature

°C/s

max. +250 /5

Bending radius (min.)

mm

15 × Ø of cable


PARAMETER :

Number of Cores x
Nominal Cross Section
Min. Breaking Load
of Conductor Strand
Current Rating
in the Air
Outer
Diameter
Total
Weight
mm^2 kN A mm kg/km
4x25 RM 3.5 84 21.5 420
4x35 RM 4.9 104 23.9 550
4x120+1x25 RM 16.8 246 43.8 1800
4x185+1x25 RM 25.9 332 50.7 2700
